I’ve configured many clusters using Cisco ASA gear, but this time i got a strange message bringing the cluster UP (active/passive) using a pair of 5510 (code asa842-k8.bin).
Error message:
Mate’s license (Licensed Cores ) is not compatible with my license (Licensed Cores ). Failover will be disabled.
Understanding Licensing models it´s always hard, because of the product evolution. But i was wondering even with same License (Security Plus) could be because of having different AnyConnect seats? After generate a demo license didn’t work, so my last guess was look to release notes and Bingo! Affected by CSCtj87870
After upgrade to 8.4(7) it worked!
Firewall 1
Serial Number: JMXyyyyyyyy
Running Permanent Activation Key: 0x0f19ee7b 0x2cf2fb8c 0x4ce23d7c 0xb0d4587c 0x013d09beLicensed features for this platform:
Maximum Physical Interfaces : Unlimited perpetual
Maximum VLANs : 100 perpetual
Inside Hosts : Unlimited perpetual
Failover : Active/Active perpetual
VPN-DES : Enabled perpetual
VPN-3DES-AES : Enabled perpetual
Security Contexts : 2 perpetual
GTP/GPRS : Disabled perpetual
AnyConnect Premium Peers : 2 perpetual
AnyConnect Essentials : Disabled perpetual
Other VPN Peers : 250 perpetual
Total VPN Peers : 250 perpetual
Shared License : Disabled perpetual
AnyConnect for Mobile : Disabled perpetual
AnyConnect for Cisco VPN Phone : Disabled perpetual
Advanced Endpoint Assessment : Disabled perpetual
UC Phone Proxy Sessions : 2 perpetual
Total UC Proxy Sessions : 2 perpetual
Botnet Traffic Filter : Disabled perpetual
Intercompany Media Engine : Disabled perpetual
This platform has an ASA 5510 Security Plus license.
The flash permanent activation key is the SAME as the running permanent key.
Firewall 2
Serial Number: JMXxxxxxxx
Running Permanent Activation Key: 0xfe13ca68 0xd8bc8063 0x697114e4 0xccd4b0c0 0x4004cbb6Licensed features for this platform:
Maximum Physical Interfaces : Unlimited perpetual
Maximum VLANs : 100 perpetual
Inside Hosts : Unlimited perpetual
Failover : Active/Active perpetual
VPN-DES : Enabled perpetual
VPN-3DES-AES : Enabled perpetual
Security Contexts : 2 perpetual
GTP/GPRS : Disabled perpetual
AnyConnect Premium Peers : 50 perpetual
AnyConnect Essentials : 250 perpetual
Other VPN Peers : 250 perpetual
Total VPN Peers : 250 perpetual
Shared License : Disabled perpetual
AnyConnect for Mobile : Disabled perpetual
AnyConnect for Cisco VPN Phone : Disabled perpetual
Advanced Endpoint Assessment : Disabled perpetual
UC Phone Proxy Sessions : 2 perpetual
Total UC Proxy Sessions : 2 perpetual
Botnet Traffic Filter : Disabled perpetual
Intercompany Media Engine : Disabled perpetual
This platform has an ASA 5510 Security Plus license.
The flash permanent activation key is the SAME as the running permanent key.
Failover On
Failover unit Primary
Failover LAN Interface: FAILOVER Ethernet0/3 (up)
Unit Poll frequency 1 seconds, holdtime 15 seconds
Interface Poll frequency 5 seconds, holdtime 25 seconds
Interface Policy 1
Monitored Interfaces 0 of 110 maximum
failover replication http
Version: Ours 8.4(7), Mate 8.4(7)
Last Failover at: 19:24:17 GMT/BDT Jul 13 2015
This host: Primary – Active
Active time: 72212 (sec)
slot 0: ASA5510 hw/sw rev (2.0/8.4(7)) status (Up Sys)
Interface outside (185.11.166.209): Normal (Not-Monitored)
Interface inside (10.1.1.254): Normal (Not-Monitored)
slot 1: empty
Other host: Secondary – Standby Ready
Active time: 0 (sec)
slot 0: ASA5510 hw/sw rev (2.0/8.4(7)) status (Up Sys)
Interface outside (0.0.0.0): Normal (Not-Monitored)
Interface inside (0.0.0.0): Normal (Not-Monitored)
slot 1: emptyStateful Failover Logical Update Statistics
Link : FAILOVER Ethernet0/3 (up)
Stateful Obj xmit xerr rcv rerr
General 10714600 0 9605 1
sys cmd 9605 0 9605 1
up time 0 0 0 0
RPC services 0 0 0 0
TCP conn 265004 0 0 0
UDP conn 9540443 0 0 0
ARP tbl 488430 0 0 0
Xlate_Timeout 0 0 0 0
IPv6 ND tbl 0 0 0 0
VPN IKEv1 SA 3 0 0 0
VPN IKEv1 P2 146 0 0 0
VPN IKEv2 SA 0 0 0 0
VPN IKEv2 P2 0 0 0 0
VPN CTCP upd 0 0 0 0
VPN SDI upd 0 0 0 0
VPN DHCP upd 0 0 0 0
SIP Session 410969 0 0 0
Route Session 0 0 0 0
User-Identity 0 0 0 0
Logical Update Queue Information
Cur Max Total
Recv Q: 0 8 9606
Xmit Q: 0 122 10979540
